RING TONGUE M5 4,0-6,0 CuZn (Sn) S/F,

Vare.nr 20202970

TE 626036-2

RING TONGUE TERMINAL 4.0-6.0 MM2 TPBR Les mer

Varianter

Minsta antal 5000 st
Tilgjengelighet webshop 5000 st
Levering 1-2 dager
0,60 NOK 2 NOK Listpris eks. mva
Legg til handlekurv
Gå til vare

  • Produktbeskrivelse

    Barrel Inside Diameter: .114 in, .162 in, 2.92 mm, 4.14 mm
    Barrel Type: Open
    Compatible With Discrete Wire Type: Stranded
    Compatible With Wire Base Material: Copper
    Number of Holes: 1
    Operating Temperature Range: -40 – 105 °C, -40 – 221 °F
    Packaging Method: Strip/Reel
    Packaging Quantity: 5000
    Product Length: .748 in, 19 mm
    Product Weight: 1.205 g
    Sealable: No
    Shape Description: RING-001
    Stud Diameter: .209 in, 5.3 mm
    Stud Size: #10
    Terminal Features: Sheared
    Terminal Orientation: Straight
    Terminal Plating Material: Tin
    Tongue Thickness: .031 in, .8 mm
    Wire Insulation Support: With
    Wire Insulation Support Retention Type: Insulation Support
    Wire Size: 11 – 10 AWG, 8233 – 10382 CMA, 4 – 6 mm²

  • Teknisk spesifikasjon

    mm2
    6
    AWG
    10
    d(mm)
    4,14
    Skruv(M)
    5
    Isolieringsfärg
    Uninsulated
    Förpackningsstorlek
    5000 Strip/Reel
